Title : Dielectric Grease Change
Applies To : MY2018, MY2019, MY2020, MY2021, MY2022, MY2023, MY2024, MY2025, MY2026 - CV, MV, HV, HX, RH, LT,
LoneStar

CHANGE LOG
Please refer to the change log text box below for recent changes to this article:
06/08/2026 - Updated notes for stainless steel nut - No longer used or available.
08/21/2024 - Updated owner. Added information about reusable battery nuts.
09/09/2020 - Added Fleetrite contact cleaner part numbers.
08/31/2020 - Updated to include assembly instructions when using dielectric grease vs. red enamel coating. Added additional part numbers.
10/07/2019 - Updated per user feedback - This article is still valid as of this date.
12/03/2018 - Update per user feedback - added chart and text as to when engineering changed from Grafo Grease.
11/06/2018 U d t d ti l
d dd d M
f t
' P/N i f
ti f
d i di tl f
N
M h





DESCRIPTION
This document will guide the user through the changes of the dielectric grease/coatings used in certain areas on all International vehicles built after 1/8/2018.
International's Electrical Engineering Team made this change to improve the longevity of the OEM coatings and to improve applications at the factory.

SYMPTOM(s)
On all International vehicles built after 1/8/2018; the color/type of dielectric grease being applied at the factory on all major electrical points has changed
depending on the location of the connection on the truck. (Please see pictures below for reference.) International Service Part Numbers will be added to this
article once available and will be orderable from Kemcrest through PDC. Until that update is available please refer to the service part section of this article to
order the grease/paint coating directly from the manufacturer.

Note: For all field repairs, service shops can continue to use Grafo grease or equivalent where it was originally applied.
Grafo may also be applied over the blue grease or red paint if Nanomech products are not available at the time of service.
Every effort should be made to reapply the same product that was originally applied by the factory.

New Changes for Color and Type of Dielectric Grease Coatings for Electrical Interconnections

EXAMPLES:

Battery box interconnections will use BLUE dielectric grease coating.
Blue TriboTuff Lithium Grease

Engine Trim interconnections will use RED dielectric paint coating.
Red GuardX Enamel Coating

SPECIAL TOOL(s) / SOFTWARE

Tool Description

Tool Number

Comments

Instructions

Small Brush

Obtain Locally

Use to apply grease

Protective Gloves

Obtain Locally

Use to protect skin from grease

Tool Resource Center

SERVICE PARTS INFORMATION

RED

BLUE

Description

MFR's Part Number (Not an Quantity Notes
International P/N)
Required

BLUE Dielectric Grease Coating

2133005

1 Lb Jar

RED Paint, Type Elec Sealant

4311832

1QT Can

Description

International Part Number

Quantity
Notes
Required

Seal, Compound, 4oz tube

472141C2

4oz Tube

Grafo 112x

BLUE Dielectric Grease Coating

NANO2133005

1 Lb Jar

Direct Ship Item

RED Paint, Type Elec Sealant

NANO4311816

RED Paint, Type Elec Sealant

NANO4311832

Only available from NanoMech directly by calling
their customer service at: (479) 725-8008
Reference Website:
http://www.nanomech.com/

Direct Ship Item
1 Quart

Direct Ship Item
Stainless Steel nut. - No longer used for battery
cable connections due to galling concerns.

NUT, HEX FLG, 3/8"-16 STAINLESS

N/A

No longer
used

Discard the nut after removal and replace it with
a 3/8"-16 battery terminal flange lock nut.

Prevailing torque nut. Replace when removed.

Nut, Battery Terminal 3/8" UNC

476074C1

As needed

Not a prevailing torque nut. Can be re-used
Nut Sealed Battery Terminal 3/8" UNC

Fleetrite Contact Cleaner

DIAGNOSTIC STEP(s)

522639C1

As needed

.
FLTACC135KK (US)
As needed Direct Ship Item
FLTACC135CKK (Canada)

Grease may cause skin & eye irritation. Wear protective clothing, gloves, and glasses.

Wash exposed skin that may have come in contact with grease thoroughly after handling.

REPAIR STEP(s)
Fully remove and clean all old dielectric grease/ paint coating from components during repair/disconnection of electrical joint. Apply the appropriate
grease/paint coating to the electrical connection components as needed after all service work is complete. Follow manufacturer's instructions for application
and clean-up of grease/ paint coating.

Assembly Instructions
Blue Grease in Battery Box
1. Clean battery terminals with a wire brush.
2. Clean battery terminals and battery studs with a liberal amount of electrical contact cleaner.
3. Dry battery terminals and battery studs with compressed air.
4. Apply dielectric grease to battery cable terminals.
5. Connect all battery terminals to proper battery studs.
6. Tighten battery terminal nuts to the proper specification 12 to 15 lb-ft (16.3 to 20.3 Nm)

The blue dielectric grease should be applied prior to assembly and torque.
Battery stud nuts are prevailing torque nuts, and should be replaced whenever they are removed.

Red Enamel on Starter, Frame, Alternator, and more
1. Clean battery terminals with a wire brush.
2. Clean battery terminals and component studs with a liberal amount of electrical contact cleaner.
3. Dry battery terminals and component studs with compressed air.
4. Connect all battery terminals to proper component studs.
5. Tighten battery terminal nuts to the proper specification.
6. Apply red enamel to the terminals as studs / bolts.

The red enamel is applied after the terminals are assembled and torqued.

WARRANTY INFORMATION
Warranty Claim Coding:
Refer to the Warranty Coding Manual for Group and Noun Codes.

Standard Repair Time(s):
Refer to the SRT Manual for Repair Times

OTHER RESOURCES
Master Service Information Site
IK0800582 - 'Red Gel Coat' Removal From Starter Studs and Electrical Connections
IK0800567 - LT Starter power connection cleaning
