NHTSA ID Number: 10136731
Manufacturer Communication Number: B614217
TSB/Document Date: 2018-05-14
Summary
MIL ACTIVATED AFTER DC CHARGING LIM FC 805526: While DC charging, the charge session may fail to start and a Check Engine Light is illuminated. Fault Code 805526 is stored in the LIM as well
If the PDF is very large, it may not load in the preview below.
Some older TSBs had multiple PDFs — visit the NHTSA Website to view all PDFs.
If the TSB PDF does not show, download or view it on the NHTSA Website.
Click on the (+) Plus Sign
Then Click on Associated Document(s)
- MaxLife Technology prevents engine breakdown with 40% better...
- Includes seal conditioners to reduce oil consumption and oil...
- Added detergents reduce sludge, corrosion, rust and deposits...
- Advanced friction-fighting additives help maximize...
- Meets or exceeds all requirements of ILSAC GF-6A, API SP...
This product presentation was made with AAWP plugin.
Search NHTSA Database for Recalls
Search NHTSA Database for Vehicle Investigations
View Latest Vehicle Investigations
Search NHTSA Database for Vehicle Complaints
View Latest Vehicle Complaints
TSB/Document ID: B614217
Replacement Service Bulletin Number:
MFR Communication Date: 2017-12-01
MFR Internal Campaign ID/Software Version:
Communication Type: Service Bulletin/Repair Instructions
NHTSA Components: ELECTRICAL SYSTEM
MFR Component System:
MFR Component Subsystem:
Previous TSB | Next TSB |
TIS Service Bulletin
Page 1 of 2
SI B61 42 17
General Electrical Systems
December 2017
Technical Service
MIL ACTIVATED AFTER DC CHARGING – LIM FC 805526
MODEL
I01
SITUATION
While DC charging, the charge session may fail to start and a Check Engine Light is illuminated. Fault Code
805526 is stored in the LIM as well
CAUSE
Certain chargers performing isolation tests on the cable can briefly go above 500V. This causes an
implausibility in the LIM.
CORRECTION
Software Update
PROCEDURE
In the case of a customer complaint similar to the situation described, begin by reading out the current software
level of the vehicle.
If the vehicle software is below I001-17-11-520: Reprogram with ISTA 4.08.2x or higher
If the vehicle software is at or above I001-17-11-520: Follow normal diagnosis through ISTA
A parts replacement will not remedy the situation and is therefore not permitted.
WARRANTY INFORMATION
Covered under the terms of the BMW
New Vehicle Limited Warranty for Passenger Cars and Light Trucks or
the BMW Certified Pre-Owned Program.
Defect Code
6138281500
Labor Operation:
Labor Allowance:
Description:
00 00 006
Refer to KSD2
Performing “vehicle test” (with vehicle
diagnosis system – checking faults) (Main
work)
Refer to KSD2
Performing “vehicle test” (with vehicle
diagnosis system – checking faults) (Plus
work)
Work time (WT)
Performing vehicle diagnosis – test module
Or:
00 00 556
And, as necessary:
61 00 006
https://www.bmwtis.net/tiscode/cgi-bin/bulletin.aspx?sie_path=/tsb/bulletins/htm_store/447... 3/8/2018
TIS Service Bulletin
Page 2 of 2
And:
61 21 528
Refer to KSD2
Connect an approved battery charger/power
supply (indicated in KSD 2 as Charging
battery)
Refer to KSD2
Recharging high-voltage battery unit (to high
voltage charging socket)
Refer to KSD2
Programming / encoding control unit(s)
And:
61 25 910
And:
61 00 730
If you are using a Main labor code for another repair, use the Plus code labor operation 00 00 556 instead of 00
00 006.
Refer to KSD2/AIR for the corresponding flat rate unit (FRU) allowances.
Work time labor operation code 61 00 006 is not considered a Main labor operation; however, it does require an
individual punch time and an explanation on the repair order and in the claim comments section.
During the same workshop visit, if a vehicle also requires another Technical Campaign or repair that also
includes programming and encoding the control units, the programming procedure may only be invoiced one
time.
Vehicle Programming and Encoding
ISTA automatically reprograms and codes all the vehicle control modules that do not have the latest software ilevel. If one or more control module failures occur “during” this programming procedure:
z
Please claim this “consequential” control module-related repair work under the defect code listed in this
bulletin with the applicable KSD2/AIR labor operations.
Control module failures that occurred “prior” to performing this programming procedure:
z
When “covered” under an applicable limited warranty, claim this control module-related repair work using
the applicable defect code and labor operations in KSD2/AIR.
[ Copyright ©2017 BMW of North America, Inc. ]
